Back-up lamps circuit for Subaru Baja I (2002-2006)
Back-up lamps circuit
A/T
BACK-UP LIGHT SWITCH (ON TRANSFER CASE)
BLK WIRE
BLK/WHT WIRE
BRN/YEL WIRE
FUSE 18
FUSE/ RELAY BOX (LEFT END OF DASH)
GR-1 (AT RIGHT FRONT CORNER OF BED)
GRN/BLK WIRE
HOT IN ON OR START
INHIBITOR SWITCH (RIGHT SIDE OF TRANSMISSION)
LEFT BACK-UP LIGHT
LEFT REAR COMBINATION LIGHT
M/T
OP CONNECTOR (BEHIND LEFT CENTER OF DASH)
RIGHT BACK-UP LIGHT
RIGHT REAR COMBINATION LIGHT
WHT/BLK WIRE
