Radio circuit, w/ navigation, audio amplifier & telematics for Subaru Ascent I (2017-2022)

ANTENNA ANTI-LOCK BRAKES SYSTEM AUDIO CASE GROUND AUX INPUT TERMINAL BLK WIRE BLU WIRE BLU/RED WIRE BRN WIRE BRN/BLK WIRE COMPUTER DATA LINES SYSTEM FUSE 29 FUSE 4 FUSE, RELAY BOX (F/B) GB-2 GRN WIRE GRY WIRE HOT AT ALL TIMES HOT W/ ACCESSORY RELAY-1 ENERGIZED LT BLU WIRE LT GRN WIRE MAIN FUSE BOX (M/B) NAVIGATION SYSTEM NAVIGATION UNIT NCA WIRE PNK WIRE REAR VIEW CAMERA CIRCUIT RED WIRE SATELLITE ANTENNA SHIELD STEREO CAMERA COVER (MICROPHONE) TAN WIRE TELEMATICS ANTENNA VIO WIRE WHT WIRE YEL WIRE

AIR BAG CONTROL MODULE BLK WIRE BLU WIRE BRN WIRE COMPUTER DATA LINES SYSTEM GB-1 GB-3 GPS ANTENNA GREEN GRN WIRE GRY WIRE GRY/RED WIRE ILLUMINATION INDICATOR LT GRN WIRE NCA WIRE ORG/ WIRE PNK WIRE PNK/BLU WIRE RED WIRE SHIELD SOS TAN WIRE TEL SUB ANTENNA TELEMATICS BUTTON VIO WIRE WHT WIRE WHT/BLU WIRE YEL/RED WIRE

BLK WIRE BLU WIRE BRN WIRE CENTER TWEETER FUSE 8 FUSE, RELAY BOX (F/B) GRN WIRE GRY WIRE HOOK HOT W/ IG 1 RELAY ENERGIZED ILL LEFT LEFT FRONT DOOR SPEAKER LEFT REAR DOOR SPEAKER LEFT SATELLITE SPEAKER LEFT SIDE TWEETER LT BLU WIRE LT GRN WIRE NCA WIRE OFF PNK WIRE PNK/BLU WIRE RED WIRE RIGHT RIGHT SIDE TWEETER ROLL CONNECTOR SATELLITE SWITCH SEEK SOURCE TAN WIRE VIO WIRE VOICE VOL (-) WHT WIRE YEL WIRE

AUDIO AMPLIFIER BLK WIRE BLU WIRE BRN WIRE BRN/WHT WIRE FUSE 34 FUSE 5 GB-11 GRN WIRE GRY WIRE HOT AT ALL TIMES LT BLU WIRE LT GRN WIRE MAIN FUSE BOX (M/B) PNK WIRE PNK/BLU WIRE RED WIRE RIGHT FRONT DOOR SPEAKER RIGHT REAR DOOR SPEAKER RIGHT SATELLITE SPEAKER SHIELD TAN WIRE VIO WIRE WHT WIRE WOOFER YEL WIRE
