Courtesy lamps circuit for Smart Fortwo III (2014-2024)

ADDITIONAL INSTRUMENTS AMBIANCE ILLUMINATION CONTROL UNIT AMBIENT LIGHT BLK WIRE BLK/BRN WIRE BLK/WHT WIRE BLU/WHT WIRE BRN/WHT WIRE CENTER LOCKING SYSTEM ACTUATOR CENTER SAM CONTROL UNIT COMPUTER DATA LINES SYSTEM DISTRIBUTION DRIVER DOOR FRONT DOME LAMP W/ READING LAMPS FRONT HEADLAMPS RELAY FRONT INTERIOR LAMP FRONT INTERIOR LAMP SWITCH FUSE 17 FUSE 21 FUSE 27 FUSE 31 GRN/WHT WIRE GRY WIRE HOT AT ALL TIMES HOT IN ON OR START LEFT FRONT LAMP UNIT LEFT FRONT READING LAMP LEFT FRONT READING LAMP SWITCH MAM PNK WIRE PNK/BRN WIRE PNK/WHT WIRE POWER RED WIRE RED/WHT WIRE RIGHT FRONT READING LAMP RIGHT FRONT READING LAMP SWITCH SYSTEM VEHICLE INTERIOR FUSE, RELAY MODULE YEL WIRE YEL/WHT WIRE

AMBIENT LIGHT BLK WIRE BLK/BRN WIRE BLK/PNK WIRE BLK/WHT WIRE CENTER COCKPIT AMBIANCE ILLUMINATION COUPE FRONT PASSENGER DOOR CENTER LOCKING SYSTEM ACTUATOR GLOVE BOX LAMP) GRN WIRE GRN/WHT WIRE LEFT COCKPIT AMBIANCE ILLUMINATION LEFT FRONT DOOR AMBIANCE ILLUMINATION LEFT FRONT FOOTWELL LAMP LOAD COMPARTMENT LAMP PNK WIRE PNK/BRN WIRE PNK/WHT WIRE RED/WHT WIRE RIGHT COCKPIT AMBIANCE ILLUMINATION RIGHT FRONT DOOR AMBIANCE ILLUMINATION RIGHT FRONT FOOTWELL LAMP RIGHT FRONT LAMP UNIT TRUNK LID/LIFTGATE RELEASE SWITCH
