Smart Fortwo II (2007-2015) seat belt multi- warning function lamp display Wiring diagram
This page shows the only wiring diagram for the component.seat belt multi- warning function lamp display, which is found in the car Smart Fortwo II (2007-2015). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram seat belt multi- warning function lamp display (1 of 1)
18 17 CAN L CAN H
4 3 14 35 20 17 31 30 CAN L CAN H HAS BFL
BLK/RED WIRE
BRAKE FLUID INDICATOR SWITCH (ON BRAKE FLUID RESERVOIR)
BRAKE FLUID, PARKING BRAKE WARNING LAMP
BRN WIRE
BRN/BLK WIRE
BRN/WHT WIRE
CAN L
COMPUTER DATA LINES SYSTEM
D BLK ON WIRE
DISPLAY
DRIVER SEAT BELT BUCKLE RESTRAINT SYSTEMS SWITCH
ESP CONTROL UNIT (LEFT CENTER OF VEHICLE UNDER CARRIAGE)
FUSE 11 FUSE 18 UNIT (UNDER LEFT SIDE OF DASH)
FUSE 12
GRN WIRE
GRN/WHT WIRE
GRY/VIO WIRE
HOT AT ALL TIMES
HOT IN ON OR START
INSTRUMENT CLUSTER
LEFT DOOR ROTARY TUMBLER MICRO SWITCH
MICRO -
PARKING BRAKE INDICATOR SWITCH (BASE OF PARKING BRAKE LEVER ASSEMBLY)
RED/PNK WIRE
RED/WHT WIRE
SAM CONTROL
SEAT BELT MULTI- WARNING FUNCTION LAMP DISPLAY
SOUND SYSTEMS
YEL WIRE
YEL/WHT WIRE
Go to component -> Seat belt warning circuit -> SEAT BELT MULTI- WARNING FUNCTION LAMP DISPLAY
