Smart Fortwo II (2007-2015) outside temperature display temperature Wiring diagram
This page shows the only wiring diagram for the component.outside temperature display temperature, which is found in the car Smart Fortwo II (2007-2015). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram outside temperature display temperature (1 of 1)
1 2 29 30 52 3 15 VBATT VBATT LOG CAN H LOG CAN L SHIELD GND
1 24 2 14 20 31 8 12 26 35 PUMP PUMP PWM
16 18 6 9 5 8 2 (-) (+) CAN H CAN L CAN H CAN L 31
5 7 8 9 15 31 CAN H CAN L
AUTOMATED MANUAL TRANSMISSION RELAY
BAT CAN H BAT CAN L SHIELD GND GND GND
BATTERY COOLING SYSTEM COOLANT PUMP (UNDER REAR OF VEHICLE)
BATTERY MANAGEMENT SYSTEM CONTROL UNIT (ON HIGH VOLTAGE BATTERY)
BLU WIRE
BLU/GRN WIRE
BRN WIRE
BRN/VIO WIRE
COMPUTER DATA LINES SYSTEM
COOLANT TEMPERATURE WARNING LAMP
ELECTRIC DRIVE, ONBOARD CHARGER COOLANT PUMP
ELECTRIC MOTOR COOLING FAN MOTOR
EVCM ELECTRIC VEHICLE CONTROL UNIT (IN LUGGAGE COMPT)
FUSE 10
FUSE 40
FUSE 41
FUSE 8
GRN WIRE
GRN/WHT WIRE
HEATING, AIR CONDITIONING OPERATING UNIT (CENTER OF DASH)
HOT AT ALL TIMES
HOT W/ MAIN RELAY ENERGIZED
INSTRUMENT CLUSTER
LEFT ELECTRIC DRIVER CONTROL MODULE
NCA WIRE
OUTSIDE TEMPERATURE DISPLAY TEMPERATURE
PUMP
RADIATOR FAN MOTOR RELAY (LEFT FRONT FOOTWELL)
RED/BRN WIRE
RED/GRN WIRE
RED/WHT WIRE
RED/YEL WIRE
RIGHT ELECTRIC DRIVER CONTROL MODULE
SAM CONTROL UNIT
SENSOR (LEFT END OF FRONT BUMPER)
VIO WIRE
VIO/WHT WIRE
WHT/BRN WIRE
WHT/GRN WIRE
YEL WIRE
Go to component -> Electric, cooling fan circuit -> OUTSIDE TEMPERATURE DISPLAY TEMPERATURE
