Smart Fortwo II (2007-2015) (left floor Wiring diagram
This page shows the only wiring diagram for the component.(left floor, which is found in the car Smart Fortwo II (2007-2015). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram (left floor (1 of 1)
BLK/GRY WIRE
BLK/WHT WIRE
BLU/YEL WIRE
BRN WIRE
COCKPIT SWITCH GROUP
FRONT HS (SIH) CONTROL UNIT (CENTER OF DASH)
FUSE
HOT AT ALL TIMES
HOT IN ON OR START
HZG LT 15 30
HZG RE
LEFT SEAT BACKREST HEATED CUSHION
LEFT SEAT HEATED CUSHION
LEFT SEAT HEATER SWITCH
PANEL)
RED WIRE
RED/BLK WIRE
RED/BLU WIRE
RED/GRN WIRE
RED/VIO WIRE
RED/YEL WIRE
RIGHT BACKREST HEATED CUSHION
RIGHT SEAT HEATED CUSHION
RIGHT SEAT HEATER SWITCH
SAM CONTROL UNIT (UNDER LEFT SIDE OF DASH)
WHT/RED WIRE
YEL/RED WIRE
Go to component -> Power seats circuit -> (LEFT FLOOR
