Smart Fortwo II (2007-2015) left electrically adjustable, heated exterior mirror Wiring diagram
This page shows the only wiring diagram for the component.left electrically adjustable, heated exterior mirror, which is found in the car Smart Fortwo II (2007-2015). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram left electrically adjustable, heated exterior mirror (1 of 1)
BLK/BLU WIRE
BLK/GRN WIRE
BRN WIRE
BRN/WHT WIRE
FUSE 12
FUSE 39
HOT AT ALL TIMES
HOT IN RUN OR START
LEFT ELECTRICALLY ADJUSTABLE, HEATED EXTERIOR MIRROR
MIRROR HEATER RELAY (IN SAM CONTROL UNIT)
NCA WIRE
RED/WHT WIRE
RIGHT ELECTRICALLY ADJUSTABLE, HEATED EXTERIOR MIRROR
SAM CONTROL UNIT (UNDER LEFT SIDE OF DASH)
Go to component -> Heated mirrors circuit -> LEFT ELECTRICALLY ADJUSTABLE, HEATED EXTERIOR MIRROR
