Smart Fortwo II (2007-2015) left door rotary tumbler micro switch Wiring diagrams
This page contains all the electrical diagrams for the component. left door rotary tumbler micro switch, in which he is found in the car Smart Fortwo II (2007-2015). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..
Wiring diagram left door rotary tumbler micro switch (1 of 2)
BLK RED/ WIRE
BLK WIRE
BLK/GRY WIRE
BLU/WHT WIRE
BRN WIRE
BRN/BLU WIRE
BRN/GRN WIRE
CENTER COCKPIT AMBIANCE ILLUMINATION
CLOSE SOFT TOP RELAY (LEFT SIDE OF LUGGAGE COMPT)
COCKPIT SWITCH GROUP
DRIVER DOOR POCKET AMBIANCE ILLUMINATION
DRIVER SIDE SWITCH
FANFARE HORNS, AIR BAG CLOCK
FRONT INTERIOR LAMP
FRONT PASSENGER DOOR POCKET AMBIANCE ILLUMINATION
FUSE
GRY WIRE
GRY/BLU WIRE
HEATING, AIR CONDITIONING OPERATING UNIT (CENTER OF DASH)
HOT AT ALL TIMES
INSTRUMENT CLUSTER
INSTRUMENT ILLUMINATION
INTERIOR LAMP SWITCH
LEFT COCKPIT AMBIANCE ILLUMINATION
LEFT CRUISE CONTROL SWITCH
LEFT DOOR ROTARY TUMBLER MICRO SWITCH
LEFT FRONT FOOTWELL LAMP
LEFT POWER WINDOW SWITCH
NCA WIRE
OPEN SOFT TOP RELAY (LEFT SIDE OF LUGGAGE COMPT)
OVERHEAD CONTROL PANEL (OCP) AMBIANCE ILLUMINATION
RED/BLK WIRE
RED/VIO WIRE
RED/WHT WIRE
RIGHT COCKPIT AMBIANCE ILLUMINATION
RIGHT CRUISE CONTROL SWITCH
RIGHT DOOR ROTARY TUMBLER MICRO SWITCH
RIGHT FRONT FOOTWELL LAMP
RIGHT POWER WINDOW
RIGHT POWER WINDOW PASSENGER
SAM CONTROL UNIT (UNDER LEFT SIDE OF DASH)
SHUTOFF-CAPABLE INTERIOR LAMP RELAY (W/ INTERIOR LIGHT PACKAGE)
SIDE SWITCH
SMART ENTRY RADIO/ PREMIUM RADIO
SPRING CONTACT (TOP OF STEERING COLUMN)
YEL WIRE
YEL/BLK WIRE
YEL/WHT WIRE
Go to component -> Interior lights circuit -> LEFT DOOR ROTARY TUMBLER MICRO SWITCH
Wiring diagram left door rotary tumbler micro switch (2 of 2)
18 17 CAN L CAN H
4 3 14 35 20 17 31 30 CAN L CAN H HAS BFL
BLK/RED WIRE
BRAKE FLUID INDICATOR SWITCH (ON BRAKE FLUID RESERVOIR)
BRAKE FLUID, PARKING BRAKE WARNING LAMP
BRN WIRE
BRN/BLK WIRE
BRN/WHT WIRE
CAN L
COMPUTER DATA LINES SYSTEM
D BLK ON WIRE
DISPLAY
DRIVER SEAT BELT BUCKLE RESTRAINT SYSTEMS SWITCH
ESP CONTROL UNIT (LEFT CENTER OF VEHICLE UNDER CARRIAGE)
FUSE 11 FUSE 18 UNIT (UNDER LEFT SIDE OF DASH)
FUSE 12
GRN WIRE
GRN/WHT WIRE
GRY/VIO WIRE
HOT AT ALL TIMES
HOT IN ON OR START
INSTRUMENT CLUSTER
LEFT DOOR ROTARY TUMBLER MICRO SWITCH
MICRO -
PARKING BRAKE INDICATOR SWITCH (BASE OF PARKING BRAKE LEVER ASSEMBLY)
RED/PNK WIRE
RED/WHT WIRE
SAM CONTROL
SEAT BELT MULTI- WARNING FUNCTION LAMP DISPLAY
SOUND SYSTEMS
YEL WIRE
YEL/WHT WIRE
Go to component -> Seat belt warning circuit -> LEFT DOOR ROTARY TUMBLER MICRO SWITCH
