Smart Fortwo II (2007-2015) front passenger door pocket ambiance illumination Wiring diagram
This page shows the only wiring diagram for the component.front passenger door pocket ambiance illumination, which is found in the car Smart Fortwo II (2007-2015). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram front passenger door pocket ambiance illumination (1 of 1)
BLK RED/ WIRE
BLK WIRE
BLK/GRY WIRE
BLU/WHT WIRE
BRN WIRE
BRN/BLU WIRE
BRN/GRN WIRE
CENTER COCKPIT AMBIANCE ILLUMINATION
CLOSE SOFT TOP RELAY (LEFT SIDE OF LUGGAGE COMPT)
COCKPIT SWITCH GROUP
DRIVER DOOR POCKET AMBIANCE ILLUMINATION
DRIVER SIDE SWITCH
FANFARE HORNS, AIR BAG CLOCK
FRONT INTERIOR LAMP
FRONT PASSENGER DOOR POCKET AMBIANCE ILLUMINATION
FUSE
GRY WIRE
GRY/BLU WIRE
HEATING, AIR CONDITIONING OPERATING UNIT (CENTER OF DASH)
HOT AT ALL TIMES
INSTRUMENT CLUSTER
INSTRUMENT ILLUMINATION
INTERIOR LAMP SWITCH
LEFT COCKPIT AMBIANCE ILLUMINATION
LEFT CRUISE CONTROL SWITCH
LEFT DOOR ROTARY TUMBLER MICRO SWITCH
LEFT FRONT FOOTWELL LAMP
LEFT POWER WINDOW SWITCH
NCA WIRE
OPEN SOFT TOP RELAY (LEFT SIDE OF LUGGAGE COMPT)
OVERHEAD CONTROL PANEL (OCP) AMBIANCE ILLUMINATION
RED/BLK WIRE
RED/VIO WIRE
RED/WHT WIRE
RIGHT COCKPIT AMBIANCE ILLUMINATION
RIGHT CRUISE CONTROL SWITCH
RIGHT DOOR ROTARY TUMBLER MICRO SWITCH
RIGHT FRONT FOOTWELL LAMP
RIGHT POWER WINDOW
RIGHT POWER WINDOW PASSENGER
SAM CONTROL UNIT (UNDER LEFT SIDE OF DASH)
SHUTOFF-CAPABLE INTERIOR LAMP RELAY (W/ INTERIOR LIGHT PACKAGE)
SIDE SWITCH
SMART ENTRY RADIO/ PREMIUM RADIO
SPRING CONTACT (TOP OF STEERING COLUMN)
YEL WIRE
YEL/BLK WIRE
YEL/WHT WIRE
Go to component -> Interior lights circuit -> FRONT PASSENGER DOOR POCKET AMBIANCE ILLUMINATION
