Smart Fortwo II (2007-2015) alternator charge monitoring, warning lamp ind Wiring diagram
This page shows the only wiring diagram for the component.alternator charge monitoring, warning lamp ind, which is found in the car Smart Fortwo II (2007-2015). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram alternator charge monitoring, warning lamp ind (1 of 1)
78 71 CAN H CAN L
9 6 CAN L CAN H
ALTERNATOR
ALTERNATOR CHARGE MONITORING, WARNING LAMP IND
BATTERY
BLK WIRE
BLK/YEL WIRE
BRN WIRE
COMPUTER DATA LINES SYSTEM
FUSE
GRN WIRE
GRN/BLU WIRE
GRN/WHT WIRE
HOT IN ON OR START
INSTRUMENT CLUSTER
ME-SFI (ME) CONTROL UNIT (RIGHT REAR OF LUGGAGE COMPT)
MULTIFUNCTION DISPLAY
POWER DISTRIBUTION SYSTEM
RED WIRE
SAM CONTROL UNIT (UNDER LEFT SIDE OF DASH)
STARTER
STARTER/ ALTER- NATOR FUSE
STARTING CIRCUIT
WHT/BLU WIRE
Go to component -> 1.0l, charging circuit -> ALTERNATOR CHARGE MONITORING, WARNING LAMP IND
