Smart Fortwo II (2007-2015) 4 2 6 5 back out back can l can h Wiring diagram
This page shows the only wiring diagram for the component.4 2 6 5 back out back can l can h, which is found in the car Smart Fortwo II (2007-2015). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram 4 2 6 5 back out back can l can h (1 of 1)
1.0L ELECTRIC
4 2 6 5 BACK OUT BACK CAN L CAN H
9 11 14 13 30 UP CAN L CAN H
AUTOMATED MANUAL TRANSMISSION CONTROL UNIT (1.0L) (UNDER DRIVER'S SEAT)
BACK SUP
BACKUP LAMP
BLU/RED WIRE
BRN WIRE
COMPUTER DATA LINES SYSTEM
FUSE 12 UNIT (UNDER LEFT SIDE OF DASH)
FUSE 8
GRN WIRE
GRN/WHT WIRE
GRY WIRE
HOT AT ALL TIMES
HOT W/ MAIN RELAY ENERGIZED
LEFT TAILLAMP
RED WIRE
RED/GRY WIRE
RED/WHT WIRE
RIGHT TAILLAMP
SAM CONTROL
WHT WIRE
YEL/RED WIRE
Go to component -> Backup lamps circuit -> 4 2 6 5 BACK OUT BACK CAN L CAN H
