Smart Fortwo II (2007-2015) 20 3 21 24 16 12 data clk gnd Wiring diagrams
This page contains all the electrical diagrams for the component. 20 3 21 24 16 12 data clk gnd, in which he is found in the car Smart Fortwo II (2007-2015). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..
Wiring diagram 20 3 21 24 16 12 data clk gnd (1 of 2)
20 3 21 24 16 12 DATA CLK GND
39 40 2 12 36 CAN L CAN H
BLK/BLU WIRE
BLU WIRE
BLU/BLK WIRE
BRN WIRE
BRN/BLK WIRE
CL (ZV) LOCKED RELAY
CL (ZV) OPEN RELAY
COMPUTER DATA LINES SYSTEM
FUEL FILLER FLAP CL (ZV) MOTOR (BEHIND RIGHT REAR BODY PANEL)
FUSE 12
FUSE 31
GRN WIRE
GRN/WHT WIRE
GRY/BLU WIRE
GRY/WHT WIRE
GRY/YEL WIRE
HORN RELAY
HORNS SYSTEM
HOT AT ALL TIMES
LEFT DOOR CL (ZV) MOTOR, LEFT DOOR ROTARY TUMBLER MICRO SWITCH
PNK WIRE
REAR END DOOR/TRUNK LID CL (ZV) RELAY
RED/BLK WIRE
RED/WHT WIRE
RIGHT DOOR CL (ZV) MOTOR, RIGHT DOOR ROTARY TUMBLER MICRO SWITCH
SAM CONTROL UNIT (UNDER LEFT SIDE OF DASH)
VIO/GRN WIRE
VIO/WHT WIRE
WHT/GRN WIRE
YEL WIRE
YEL/BLK WIRE
YEL/PNK WIRE
YEL/WHT WIRE
ZV OPEN ZV CLOSE PNK WIRE
Go to component -> Anti-theft circuit (1 of 2) -> 20 3 21 24 16 12 DATA CLK GND
Wiring diagram 20 3 21 24 16 12 data clk gnd (2 of 2)
20 3 21 24 16 12 DATA CLK GND
39 40 2 12 36 CAN L CAN H
BLK/BLU WIRE
BLU WIRE
BLU/BLK WIRE
BRN WIRE
BRN/BLK WIRE
CL (ZV) LOCKED RELAY
CL (ZV) OPEN RELAY
COMPUTER DATA LINES SYSTEM
FUEL FILLER FLAP CL (ZV) MOTOR (BEHIND RIGHT REAR BODY PANEL)
FUSE 12
FUSE 31
GRN WIRE
GRN/WHT WIRE
GRY/BLU WIRE
GRY/WHT WIRE
GRY/YEL WIRE
HORN RELAY
HORNS SYSTEM
HOT AT ALL TIMES
LEFT DOOR CL (ZV) MOTOR, LEFT DOOR ROTARY TUMBLER MICRO SWITCH
PNK WIRE
REAR END DOOR/TRUNK LID CL (ZV) RELAY
RED/BLK WIRE
RED/WHT WIRE
RIGHT DOOR CL (ZV) MOTOR, RIGHT DOOR ROTARY TUMBLER MICRO SWITCH
SAM CONTROL UNIT (UNDER LEFT SIDE OF DASH)
VIO/GRN WIRE
VIO/WHT WIRE
WHT/GRN WIRE
YEL WIRE
YEL/BLK WIRE
YEL/PNK WIRE
YEL/WHT WIRE
ZV OPEN ZV CLOSE PNK WIRE
Go to component -> Power door locks circuit (1 of 2) -> 20 3 21 24 16 12 DATA CLK GND
