Smart Fortwo II (2007-2015) 1 2 3 4 5 6 back up 30 31 back out can h can l Wiring diagram
This page shows the only wiring diagram for the component.1 2 3 4 5 6 back up 30 31 back out can h can l, which is found in the car Smart Fortwo II (2007-2015). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram 1 2 3 4 5 6 back up 30 31 back out can h can l (1 of 1)
1 2 3 4 5 6 BACK UP 30 31 BACK OUT CAN H CAN L
5 8 CAN H CAN L
BRN WIRE
COMPUTER DATA LINES SYSTEM
DRIVE DIAGNOSIS INDICATOR LAMP
DRIVE DIAGNOSIS WARNING LAMP
ELECTRONIC SELECTOR LEVER MODULE CONTROL UNIT (UNDER CENTER CONSOLE)
FUSE 24 (UNDER LEFT SIDE OF DASH)
FUSE 8
GRN WIRE
GRN/WHT WIRE
HOT AT ALL TIMES
HOT W/ MAIN RELAY ENERGIZED
INSTRUMENT CLUSTER
LEFT TAILLAMP
RED/GRY WIRE
RED/YEL WIRE
RIGHT TAILLAMP
SAM CONTROL UNIT
YEL/RED WIRE
Go to component -> Electric, transmission circuit -> 1 2 3 4 5 6 BACK UP 30 31 BACK OUT CAN H CAN L
