Tire pressure monitoring circuit for Scion xD I (2007-2014)

1 2 3 CLSW SPD TC 1 4 5 RDA GND 4 5 6 7 8 9 10 11 12 TACH IND BLK WIRE BLU WIRE BRN WIRE COMBINATION METER ASSEMBLY COMPUTER DATA LINES SYSTEM ENGINE CONTROL MODULE (RIGHT REAR OF ENGINE COMPT) GND SIL GRN WIRE GRY WIRE HOT IN ON OR START HOT IN ON OR START ECU-IG FUSE INSTRUMENT PANEL J/B (BEHIND LEFT END OF DASH) J/B 6 (BEHIND RIGHT KICK PANEL) LED DRIVER LT BLU WIRE LT GRN WIRE MET FUSE RED WIRE TACH TAN WIRE TIRE PRESSURE IND TIRE PRESSURE WARNING ANTENNA, RECEIVER (LEFT "C" PILLAR) TIRE PRESSURE WARNING ECU (BEHIND RIGHT SIDE OF DASH) TIRE PRESSURE WARNING RESET SWITCH VIO WIRE WHT WIRE WHT/BLK WIRE
