Car Wiring Diagrams for Charging circuit for Scion xD I (2007-2014)

ALT ALT FUSE ALT-S FUSE BATTERY BLK WIRE BLU WIRE CHARGE IND COMBINATION METER ENGINE ROOM J/B (LEFT SIDE OF ENGINE COMPT) ENGINE ROOM R/B (LEFT SIDE OF ENGINE COMPT) FUSIBLE LINK BLOCK MAIN FUSE (LEFT REAR OF ENGINE COMPT) GAUGE FUSE GENERATOR REGULATOR ASSEMBLY (LOWER LEFT FRONT OF ENGINE) GRN WIRE HOT IN ON OR START INSTRUMENT PANEL J/B (BEHIND LEFT END OF DASH) LT BLU WIRE MET FUSE PNK WIRE STARTING CIRCUIT W/O DRL W/ DRL WHT WIRE
