Cooling fan circuit for Scion xD I (2007-2014)
Cooling fan circuit
41 49 21 22 CAN H CAN L FAN
96 97 122 121 PNK ETHW THW NE+ NE- WIRE
BLK WIRE
BLK/ WHT WIRE
BLU WIRE
BRN WIRE
COMPUTER DATA LINES SYSTEM
COOLING FAN MOTOR (BEHIND RADIATOR)
COOLING FAN RESISTOR (LEFT FRONT OF ENGINE COMPT)
CRANKSHAFT POSITION SENSOR
E.F.I. ENGINE COOLANT TEMPERATURE SENSOR (REAR OF ENGINE)
ECM (ENGINE CONTROL MODULE) (RIGHT REAR OF ENGINE COMPT)
ENGINE ROOM J/B (LEFT SIDE OF ENGINE COMPT)
ENGINE ROOM R/B (LEFT SIDE OF ENGINE COMPT)
FAN 1 RELAY
FAN 2 RELAY
GRN WIRE
HOT AT ALL TIMES
HOT IN ON OR START INSTRUMENT PANEL J/B ECU-IG FUSE (BEHIND LEFT END OF DASH)
LT GRN WIRE
NCA WIRE
PNK WIRE
RDI FUSE
RED WIRE
WHT WIRE
WHT/BLK WIRE
