Immobilizer circuit for Scion xD I (2007-2014)
Immobilizer circuit
11 10 41 49 IMI IMO CANH CANL
AGND
ASSEMBLY
BLK WIRE
BLU WIRE
CODE
COMPUTER DATA LINES SYSTEM
CTY
ECU-B FUSE
EFII
EFIO
ENGINE CONTROL MODULE (ECM) (RIGHT REAR OF ENGINE COMPT)
ENGINE ROOM R/B (LEFT SIDE OF ENGINE COMPT)
GRN WIRE
GRY WIRE
HOT AT ALL TIMES
HOT IN ON OR START
IGN FUSE
IND
INSTRUMENT PANEL J/B (BEHIND LEFT END OF DASH)
J/B 5 (BEHIND LEFT KICK PANEL)
J/B 6 (BEHIND RIGHT KICK PANEL)
LT GRN WIRE
PNK WIRE
RED WIRE
SECURITY IND
SECURITY WARNING LIGHT
TAN WIRE
TRANSPONDER KEY AMPLIFIER (CENTER OF DASH)
TRANSPONDER KEY COIL
TRANSPONDER KEY ECU ASSEMBLY (CENTER OF DASH)
TXCT
UNLOCK WARNING SWITCH
VIO WIRE
WHT WIRE
WHT/BLK WIRE
YEL WIRE
