Scion xD I (2007-2014) swg pnk Wiring diagram
This page shows the only wiring diagram for the component.swg pnk, which is found in the car Scion xD I (2007-2014). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram swg pnk (1 of 1)
1 2 3 4 5 6 7 8 9 10 FR+ FL+ PNK WIRE
1 2 3 4 5 6 PNK WIRE
1 2 3 4 5 6 RR+ RL+ RR-
AGND
ALO
AMPLIFIER MICROPHONE ASSEMBLY
ANTENNA
ANTENNA AMPLIFIER ASSEMBLY (BEHIND RIGHT END OF DASH)
ARI ASGN ALI AUXG AUXI
ARO
ASGN
AUXO
BLK WIRE
BLU WIRE
COMBINATION METER ASSEMBLY
COMPUTER DATA LINES SYSTEM
DOME FUSE
ENGINE ROOM R/B (LEFT SIDE OF ENGINE COMPT)
FR- FL- GND ANT
FUSE
GRN WIRE
GRY WIRE
HOT AT ALL TIMES
HOT IN ON OR ACC
I/F CAN I/F
ILL- RL-
INSTRUMENT PANEL J/B (BEHIND LEFT END OF DASH)
LEFT FRONT SPEAKER ASSEMBLY 1
LEFT FRONT SPEAKER ASSEMBLY 2
LEFT REAR SPEAKER ASSEMBLY
LEFT STEERING PAD SWITCH
LT BLU WIRE
LT GRN WIRE
MACC
MCO-
MIN+ MACC
MIN- SGND
NCA WIRE
PNK PNK WIRE
PNK WIRE
RADIO RECEIVER ASSEMBLY
RED WIRE
RIGHT FRONT SPEAKER ASSEMBLY 1
RIGHT FRONT SPEAKER ASSEMBLY 2
RIGHT REAR SPEAKER ASSEMBLY
SEEK- MODE
SEEK- STEERING PAD VOL+ SWITCH
SPIRAL CABLE SUB-ASSEMBLY (STEERING COLUMN)
STEREO JACK ADAPTER ASSEMBLY 1
SWG PNK WIRE
TAN WIRE
UDO+
UJSG
UPI
VIO WIRE
VOL (-)
WHT WIRE
WHT/BLK WIRE
YEL WIRE
Go to component -> Radio circuit -> SWG PNK WIRE
