Scion xD I (2007-2014) pnk slu+ slu- slt+ slt- etho Wiring diagram
This page shows the only wiring diagram for the component.pnk slu+ slu- slt+ slt- etho, which is found in the car Scion xD I (2007-2014). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram pnk slu+ slu- slt+ slt- etho (1 of 1)
+B STA MREL SPD IGSW STP
6 5 4 3 2 1 VPA EPA VCPA
BLK WIRE
BLU WIRE
BRN WIRE
COMPUTER DATA LINES
ECM (ENGINE CONTROL MODULE) (RIGHT REAR OF ENGINE COMPT)
ECU-B FUSE ETCS FUSE
EFI FUSE
EFI RELAY
ELECTRONICALLY CONTROLLED TRANSMISSION SOLENOID (LEFT REAR OF TRANSMISSION)
ENGINE ROOM J/B (LEFT SIDE OF ENGINE COMPT)
ENGINE ROOM R/B (LEFT SIDE OF ENGINE COMPT)
GAUGE FUSE
GRN WIRE
GRY WIRE
HOT AT ALL TIMES
HOT AT ALL TIMES INSTRUMENT PANEL J/B (BEHIND LEFT END OF DASH) STOP FUSE
IGN FUSE
LT BLU WIRE
NT+ NT- THW ETHW NE+ NE-
ODMS
ORG/ WIRE
PNK SLU+ SLU- SLT+ SLT- ETHO WIRE
PNK WIRE
RED WIRE
RELAY ENERGIZED
STAR
STARTING/CHARGING SYSTEM
SYSTEM
TAN WIRE
VCPA EPA VPA +BM EC CANH CANL TC BATT
VIO WIRE
WHT WIRE
WHT/BLK WIRE
YEL WIRE
Go to component -> Transmission circuit (1 of 2) -> PNK SLU+ SLU- SLT+ SLT- ETHO WIRE
