Scion xD I (2007-2014) hot in on or start Wiring diagram
This page shows the only wiring diagram for the component.hot in on or start, which is found in the car Scion xD I (2007-2014). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram hot in on or start (21 of 21)
BACK DOOR
BLU WIRE
HOT IN ON OR START
INSTRUMENT PANEL J/B (BEHIND LEFT END OF DASH)
ON OFF
ON+WASHER
REAR WASHER MOTOR, PUMP ASSEMBLY (RIGHT FRONT OF ENGINE COMPT)
REAR WIPER MOTOR (CENTER OF BACK DOOR)
REAR WIPER/ WASHER SWITCH
RR WIP FUSE
TAN WIRE
WASHER
WHT WIRE
WHT/ BLK WIRE
WHT/BLK WIRE
WINDSHIELD WIPER SWITCH ASSEMBLY
WSH FUSE
YEL WIRE
Go to component -> Rear wiper/washer circuit -> HOT IN ON OR START
