Scion xD I (2007-2014) fuse block (behind wiring diagram
This page shows the only wiring diagram for the component.fuse block (behind, which is found in the car Scion xD I (2007-2014). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
fuse block (behind wiring diagram (1 of 1)
1 2 3 4 5 6 7 8 9 10 11 12 IG
41 49 CANH CANL
BLK WIRE
BLU WIRE
COMPUTER DATA LINES SYSTEM
DL RB NL RL PL
ENGINE CONTROL MODULE (RIGHT REAR OF ENGINE COMPT)
FUSE (LEFT END OF DASH)
FUSE BLOCK (BEHIND
GAUGE FUSE
GRN WIRE
HOT AT ALL TIMES
HOT W/ ACC RELAY 2 ENERGIZED
INSTRUMENT PANEL J/B (BEHIND LEFT END OF DASH)
J/B 6 (BEHIND RIGHT KICK PANEL)
KEY INTERLOCK SOLENOID (STEERING COLUMN)
KLS+
RED WIRE
RELAY ENERGIZED
SHIFT LOCK CONTROL ECU SUB-ASSEMBLY
SHIFT LOCK SOLENOID
SLS+
STOP FUSE
STOP LIGHT SWITCH (BRACKET, ABOVE BRAKE PEDAL)
WHT WIRE
WHT/ BLK WIRE
WHT/BLK WIRE
Go to component -> Shift interlock circuit -> FUSE BLOCK (BEHIND
