Scion xD I (2007-2014) combination meter assembly Wiring diagrams

BLK WIRE BLU WIRE COMBINATION METER ASSEMBLY FRONT WASHER MOTOR, PUMP ASSEMBLY (RIGHT FRONT OF ENGINE COMPT) FRONT WASHER SWITCH FRONT WIPER SWITCH GRN WIRE HIGH MIST HOT IN ON OR START INSTRUMENT PANEL J/B INSTRUMENT PANEL J/B (BEHIND LEFT END OF DASH) LO OFF INT MET FUSE MIST SOLID STATE WASHER IND WHT WIRE WHT/BLK WIRE WINDSHIELD WASHER MOTOR, PUMP ASSEMBLY (RIGHT FRONT OF ENGINE COMPT) WINDSHIELD WIPER MOTOR (LEFT SIDE OF FIREWALL) WINDSHIELD WIPER SWITCH ASSEMBLY WIP FUSE WSH FUSE (BEHIND LEFT END OF DASH) WIPER RELAY YEL WIRE

11 12 14 13 DBE+ DBE- DSP+ DSP- 12 13 FSP+ FSP- 22 13 16 21 25 26 17 23 CANL CANH SIL AIR BAG INDICATOR (AIR BAG ON/ AIR BAG OFF) BLK WIRE BLU WIRE BRN WIRE BUZZER CAN CONTROLLER CAN I/F CENTER AIR BAG SENSOR ASSEMBLY (UNDER FRONT OF CENTER CONSOLE) COMBINATION METER ASSEMBLY COMPUTER DATA LINES SYSTEM DCTY DIA DOOR IND DRIVER'S SEAT BELT IND ENGINE ROOM R/B (LEFT SIDE OF ENGINE COMPT) FUSE GAUGE FUSE GRN WIRE GRY WIRE HEAD TAIL HEADLIGHT DIMMER SWITCH ASSEMBLY HOT AT ALL TIMES ECU-B FUSE HOT AT ALL TIMES INSTRUMENT PANEL J/B (BEHIND LEFT END OF DASH) HOT IN ON OR START IGN FUSE ILLUMINATION I/F INSTRUMENT PANEL J/B (BEHIND LEFT END OF DASH) J/B 5 (BEHIND LEFT KICK PANEL) J/B 6 (BEHIND RIGHT KICK PANEL) LED DRIVER LEFT FRONT OCCUPANT DETECTION SENSOR LEFT FRONT SEAT INNER BELT ASSEMBLY LSP + LT BLU WIRE MAIN BODY ECU MET FUSE OCCUPANT DETECTION ECU (UNDER FRONT PASSENGER'S SEAT) OFF LIGHT CONTROL SWITCH P-AB P-AB PAON PAON PASSENGER SEAT BELT WARNING LIGHT ASSEMBLY PBEW RED WIRE T-LP RELAY TAN WIRE UNLOCK WARNING SWITCH ASSEMBLY WHT WIRE WHT/BLK WIRE YEL WIRE YEL/RED WIRE

1 2 3 4 5 6 7 8 9 10 FR+ FL+ PNK WIRE 1 2 3 4 5 6 PNK WIRE 1 2 3 4 5 6 RR+ RL+ RR- AGND ALO AMPLIFIER MICROPHONE ASSEMBLY ANTENNA ANTENNA AMPLIFIER ASSEMBLY (BEHIND RIGHT END OF DASH) ARI ASGN ALI AUXG AUXI ARO ASGN AUXO BLK WIRE BLU WIRE COMBINATION METER ASSEMBLY COMPUTER DATA LINES SYSTEM DOME FUSE ENGINE ROOM R/B (LEFT SIDE OF ENGINE COMPT) FR- FL- GND ANT FUSE GRN WIRE GRY WIRE HOT AT ALL TIMES HOT IN ON OR ACC I/F CAN I/F ILL- RL- INSTRUMENT PANEL J/B (BEHIND LEFT END OF DASH) LEFT FRONT SPEAKER ASSEMBLY 1 LEFT FRONT SPEAKER ASSEMBLY 2 LEFT REAR SPEAKER ASSEMBLY LEFT STEERING PAD SWITCH LT BLU WIRE LT GRN WIRE MACC MCO- MIN+ MACC MIN- SGND NCA WIRE PNK PNK WIRE PNK WIRE RADIO RECEIVER ASSEMBLY RED WIRE RIGHT FRONT SPEAKER ASSEMBLY 1 RIGHT FRONT SPEAKER ASSEMBLY 2 RIGHT REAR SPEAKER ASSEMBLY SEEK- MODE SEEK- STEERING PAD VOL+ SWITCH SPIRAL CABLE SUB-ASSEMBLY (STEERING COLUMN) STEREO JACK ADAPTER ASSEMBLY 1 SWG PNK WIRE TAN WIRE UDO+ UJSG UPI VIO WIRE VOL (-) WHT WIRE WHT/BLK WIRE YEL WIRE

-SL +SL +SR -SR -SL +SR +SL 1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 PD- PD+ BBL+ BBL- BCL- BCL+ BBR- BBR+ BCL- BCL+ BCR+ BCR- BCR+ BCR+ BLK WIRE BLU WIRE BRN WIRE CAN I/F CANL PAON CENTER AIR BAG SENSOR ASSEMBLY (UNDER FRONT OF CENTER CONSOLE) COMBINATION METER ASSEMBLY COMPUTER DATA LINES SYSTEM COMPUTER DATA LINES SYSTEM (BEHIND CENTER OF DASH) CPU CAN CONTROLLER GRN WIRE GRY WIRE ICD- ICD+ BBD+ SFD+ SFD- DBE+ DBE- DSP- DSP+ BBD- ICL- ICR+ LBE- LSP- LSP+ LED DRIVER LEFT FRONT PRETENSIONER (NEAR BASE OF LEFT "B" PILLAR) LEFT FRONT SEAT INNER BELT ASSEMBLY LEFT SIDE AIR BAG SQUIB CIRCUIT (LEFT SIDE OF DRIVER'S SEAT BACK) P- P+ D+ D- PP+ PP- SFP- SFP+ BBP+ ICP+ ICP- BBP- FSP+ FSP- RED WIRE RIGHT CURTAIN SHIELD AIR BAG ASSEMBLY (ROOF ABOVE RIGHT DOORS) RIGHT FRONT PRETENSIONER (NEAR BASE OF RIGHT "B" PILLAR) RIGHT FRONT SIDE AIR BAG SENSOR ASSEMBLY (BASE OF RIGHT "B" PILLAR) RIGHT REAR SIDE AIR BAG SENSOR ASSEMBLY (RIGHT "C" PILLAR) RIGHT SIDE AIR BAG SQUIB CIRCUIT (RIGHT SIDE OF FRONT PASSENGER'S SEAT BACK) SIL P-AB SR- SRS IND WHT WIRE WHT/BLK WIRE YEL WIRE YEL/BLK WIRE YEL/GRN WIRE YEL/RED WIRE

1 2 3 CLSW SPD TC 1 4 5 RDA GND 4 5 6 7 8 9 10 11 12 TACH IND BLK WIRE BLU WIRE BRN WIRE COMBINATION METER ASSEMBLY COMPUTER DATA LINES SYSTEM ENGINE CONTROL MODULE (RIGHT REAR OF ENGINE COMPT) GND SIL GRN WIRE GRY WIRE HOT IN ON OR START HOT IN ON OR START ECU-IG FUSE INSTRUMENT PANEL J/B (BEHIND LEFT END OF DASH) J/B 6 (BEHIND RIGHT KICK PANEL) LED DRIVER LT BLU WIRE LT GRN WIRE MET FUSE RED WIRE TACH TAN WIRE TIRE PRESSURE IND TIRE PRESSURE WARNING ANTENNA, RECEIVER (LEFT "C" PILLAR) TIRE PRESSURE WARNING ECU (BEHIND RIGHT SIDE OF DASH) TIRE PRESSURE WARNING RESET SWITCH VIO WIRE WHT WIRE WHT/BLK WIRE

BLK WIRE BLU WIRE BRN WIRE CAN CONTROLLER CAN I/F COMBINATION METER ASSEMBLY COMPUTER DATA LINES SYSTEM CONSOLE) CRANKSHAFT POSITION SENSOR DISPLAY DL NL RL LL PL RB E.F.I. ENGINE COOLANT TEMPERATURE SENSOR (REAR OF ENGINE) GRN WIRE GRY WIRE I/F I/F INSTRUMENT PANEL J/B LED DRIVER LT BLU WIRE MET FUSE NCA WIRE NL DL RL LL PL RB NSSD PARK/NEUTRAL POSITION SWITCH (LEFT REAR OF TRANSMISSION) PNK WIRE RED WIRE RELAY ENERGIZED SHIFT LOCK CONTROL ECU SUB-ASSEMBLY (UNDER CENTER SKID CONTROL ECU (LEFT SIDE OF ENGINE COMPT) SPEEDOMETER STARTING/ CHARGING SYSTEM TACHOMETER TAN WIRE TRANSMISSION CONTROL SWITCH TRANSMISSION REVOLUTION SENSOR (TURBINE) (LEFT REAR OF TRANSMISSION) VIO WIRE WHT WIRE YEL WIRE
