Scion xD I (2007-2014) 23 19 bcty exterior trly lights system Wiring diagrams
This page contains all the electrical diagrams for the component. 23 19 bcty exterior trly lights system, in which he is found in the car Scion xD I (2007-2014). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..
Wiring diagram 23 19 bcty exterior trly lights system (1 of 2)
11 12 PNK WIRE
15 2 3 HORN ACT+ ACT-
17 16 15 PRG RDA BZR
22 23 COMPUTER CANL CANH DATA LINES SYSTEM
23 19 BCTY EXTERIOR TRLY LIGHTS SYSTEM
5 21 14 2 LSWP LSWD
BLU WIRE
BRN WIRE
D/L FUSE
DCTY
ECU-B FUSE
ECU-IG FUSE
EHW
ENGINE ROOM R/B (LEFT SIDE OF ENGINE COMPT)
FLASH RELAY
FUSE
GRN WIRE
GRY WIRE
HEADLIGHTS HRLY SYSTEM 20 22 PCTY RRCY
HORNS SYSTEM
HOT AT ALL TIMES
HOT IN ON OR ACC
HOT IN ON OR START
IG ALTB HAZ BECU KSW
INSTRUMENT PANEL J/B (BEHIND LEFT END OF DASH)
J/B 5 (BEHIND LEFT KICK PANEL)
J/B 6 (BEHIND RIGHT KICK PANEL)
LEFT "C" PILLAR)
LEFT FRONT DOOR W/ MOTOR LOCK ASSEMBLY (REAR OF LEFT FRONT DOOR)
LOCK
LSSR
LT BLU WIRE
LT GRN WIRE
MAIN BODY ECU
PNK PNK WIRE
PNK WIRE
POWER WINDOW REGULATOR MASTER SWITCH ASSEMBLY
RED WIRE
RIGHT FRONT DOOR CONTROL SWITCH ASSEMBLY
RIGHT REAR DOOR W/ MOTOR LOCK ASSEMBLY (REAR OF RIGHT REAR DOOR)
TAN WIRE
UNLOCK
UNLOCK DETECTION
UNLOCK LEFT REAR DOOR W/ MOTOR LOCK ASSEMBLY (REAR OF LEFT REAR DOOR)
UNLOCK WARNING SWITCH ASSEMBLY
WHT WIRE
WHT/BLK WIRE
YEL WIRE
Go to component -> Forced entry circuit (1 of 2) -> 23 19 BCTY EXTERIOR TRLY LIGHTS SYSTEM
Wiring diagram 23 19 bcty exterior trly lights system (2 of 2)
