Car Wiring Diagrams for Shift interlock circuit for Scion xB II facelift (2010-2015)

BLK WIRE BLU WIRE COMPUTER DATA LINES SYSTEM ECU- IG 1 FUSE ECU-IG 2 FUSE ENGINE CONTROL MODULE (LEFT SIDE OF ENGINE COMPT) FUSE GRN WIRE GRY WIRE HOT AT ALL TIMES HOT IN ON OR ACC HOT IN ON OR START INSTRUMENT PANEL J/B (LEFT SIDE OF DASH) J/B 4 (CENTER OF DASH) KEY INTERLOCK SOLENOID (LEFT SIDE OF DASH) KLS+ PARK/NEUTRAL POSITION SWITCH (LEFT REAR OF TRANSMISSION) RB PL DL NL RL SHIFT LOCK SOLENOID SHIFT LOCK STP CONTROL ECU (CENTER OF DASH) SLS+ SLS- STOP FUSE STOP LIGHT SWITCH (LEFT SIDE OF DASH) VIO WIRE WHT WIRE YEL WIRE
