Power mirrors circuit for Scion xB II facelift (2010-2015)
Power mirrors circuit
BLK WIRE
BLU WIRE
FUSE
GRN WIRE
GRY WIRE
HOT IN ACC OR ON INSTRUMENT PANEL J/B (LEFT SIDE OF DASH)
INSTRUMENT PANEL J/B (LEFT SIDE OF DASH)
J/B 4 (CENTER OF DASH)
LEFT
LEFT OUTER REAR VIEW MIRROR
LEFT UP
LT GRN WIRE
M+ MV
M+ MV MH
OPERATION SWITCH
OUTER MIRROR SWITCH
PNK WIRE
RIGHT
RIGHT DOWN
RIGHT OUTER REAR VIEW MIRROR
SELECT SWITCH
UP DOWN
VL HR M+
WHT WIRE
YEL WIRE
