Car Wiring Diagrams for Defoggers circuit for Scion xB II facelift (2010-2015)

BLK WIRE DEF FUSE DEF RELAY ECU-IG 2 FUSE ENGINE CONTROL MODULE (LEFT SIDE OF ENGINE COMPT) GRN WIRE HEATER MIRROR HOT AT ALL TIMES HOT IN ON OR START HTR-IG FUSE INSTRUMENT PANEL J/B (LEFT SIDE OF DASH) INTEGRATION CONTROL, PANEL ASSEMBLY J/B 4 (CENTER OF DASH) LEFT "C" PILLAR) LEFT OUTER REAR VIEW MIRROR MIR HTR FUSE MIRROR HEATER NOISE FILTER (STOP LIGHT, REAR WINDOW DEFOGGER) (LEFT "C" PILLAR) REAR WINDOW DEFOGGER REAR WINDOW DEFOGGER SWITCH RIGHT OUTER REAR VIEW MIRROR TIMER CIRCUIT W/O MIRROR HEATER WHT WIRE WHT/BLK WIRE YEL WIRE
