Manual a/c circuit for Scion xB II facelift (2010-2015)
Manual a/c circuit (1 of 2)
A/C AMPLIFIER (CENTER OF DASH)
A/C COMPRESSOR
A/C LED
A/C PRESSURE SENSOR (RIGHT REAR OF ENGINE COMPT)
A/C THERMISTOR (LOWER CENTER OF DASH)
BLK WIRE
BLU WIRE
BLU/WHT WIRE
BRN WIRE
CAN (-) CAN (+)
CANH CANL SG-2
ECU-IG 2 FUSE
ENGINE CONTROL MODULE (LEFT SIDE OF ENGINE COMPT)
ENGINE COOLANT TEMPERATURE SENSOR (LEFT FRONT OF ENGINE)
ENGINE ROOM J/B (LEFT SIDE OF ENGINE COMPT)
FAN FAN ETHW THW
GRN WIRE
GRY WIRE
HOT AT ALL TIMES
HOT IN ON OR START
HTR FUSE
HTR RELAY
HTR-IG FUSE
INSTRUMENT PANEL J/B (LEFT SIDE OF DASH)
J/B 4 (CENTER OF DASH)
LT GRN WIRE
ORG/ WIRE
PNK WIRE
PRE SOL+ IG+ SBLW TE SG-3 GND
RED WIRE
SOL- SOL+
VIO WIRE
WHT WIRE
WHT/BLK WIRE
YEL WIRE
Manual a/c circuit (2 of 2)
A/C SWITCH
A/M, A/C SWITCH
AIR INLET CONTROL SWITCH
BLK WIRE
BLK/ WHT WIRE
BLOWER MOTOR RESISTOR (RIGHT SIDE OF DASH)
BLU WIRE
BLU/BLK WIRE
CDS FAN FUSE
DEF- LOGIC SWITCH
ECU- IG 1 FUSE
ENGINE ROOM
ENGINE ROOM R/B (LEFT SIDE OF ENGINE COMPT)
F/R SWITCH
FAN 1 RELAY
FAN 2 RELAY
FAN 3 RELAY
FRS DAMPER SERVO MOTOR (RIGHT SIDE OF DASH)
GRN WIRE
GRY WIRE
HOT AT ALL TIMES
HOT IN ON OR START
INSTRUMENT PANEL J/B (LEFT SIDE OF DASH)
INTEGRATION CONTROL, PANEL ASSEMBLY
J/B (LEFT SIDE OF ENGINE COMPT)
ORG/ WIRE
PNK REC WIRE
PNK WIRE
RDI FAN FUSE
RED WIRE
VIO WIRE
WHT WIRE
WHT/BLK WIRE
YEL WIRE
