Scion xB II facelift (2010-2015) security ind et Wiring diagram
This page shows the only wiring diagram for the component.security ind et, which is found in the car Scion xB II facelift (2010-2015). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram security ind et (1 of 1)
11 10 41 49 PNK IMI IMO CANH CANL WIRE
AGND
BLK WIRE
BLU WIRE
BRN WIRE
COMBINATION METER
COMPUTER DATA LINES SYSTEM
CTY
EFII
ENGINE CONTROL MODULE (LEFT SIDE OF ENGINE COMPT)
ENGINE ROOM R/B (LEFT SIDE OF ENGINE COMPT)
FUSE
GRN WIRE
HOT AT ALL TIMES
HOT IN ON OR START
IGN FUSE
IND
INSTRUMENT PANEL J/B (LEFT SIDE OF DASH)
J/B 4 (CENTER OF DASH)
LT GRN WIRE
LT GRN/BLK WIRE
PNK CODE WIRE
PNK EFIO WIRE
PNK WIRE
RED WIRE
SECURITY IND ET
TRANSPONDER KEY AMPLIFIER (STEERING COLUMN)
TRANSPONDER KEY COIL
TRANSPONDER KEY ECU ASSEMBLY (CENTER OF DASH)
TXCT
UNLOCK WARNING SWITCH
WHT WIRE
WHT/BLK WIRE
YEL WIRE
Go to component -> Anti-theft circuit -> SECURITY IND ET
