Scion xB II facelift (2010-2015) meter fuse wiring diagram
This page shows the only wiring diagram for the component.meter fuse, which is found in the car Scion xB II facelift (2010-2015). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
meter fuse wiring diagram (11 of 11)
-1 +2
BLK WIRE
BLU WIRE
COMBINATION METER
FRONT WASHER (BEHIND MOTOR RIGHT (BEHIND RIGHT HEADLIGHT) HEADLIGHT ASSEMBLY)
FRONT WASHER SWITCH EW WF
FRONT WIPER MOTOR (LEFT REAR OF ENGINE COMPT)
FRONT WIPER SWITCH
GRN WIRE
HIGH MIST
HOT IN ON OR START
INSTRUMENT PANEL J/B (LEFT SIDE OF DASH)
J/B 4 (CENTER OF DASH)
LOW OFF INT
LT GRN WIRE
METER FUSE
MIST
OFF LOW INT
PNK WIRE
RED WIRE
RIGHT END OF DASH)
SOLID STATE
WASHER FUSE
WASHER LEVEL IND
WASHER LEVEL WARNING SWITCH (WASHER FLUID RESERVOIR)
WHT WIRE
WHT/BLK WIRE
WINDSHIELD WIPER SWITCH
WIPER FUSE
WIPER RELAY
Go to component -> Front wiper/washer circuit -> METER FUSE
