Scion xB II facelift (2010-2015) altb ig becu wiring diagram
This page shows the only wiring diagram for the component.altb ig becu, which is found in the car Scion xB II facelift (2010-2015). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
altb ig becu wiring diagram (1 of 1)
ALTB IG BECU
BLU WIRE
BRN WIRE
COURTESY BACK DOOR LOCK ASSEMBLY (REAR TAILGATE)
DCTY
DIODE (ROOM LIGHT) (RIGHT SIDE
DOME FUSE ROOM R/B (LEFT SIDE OF ENGINE COMPT)
DOOR
DOOR FUSE FUSE
ECU- IG 1 FUSE
ECU-B FUSE
ENGINE
FLOOR PAN)
HOT AT ALL TIMES
HOT AT HOT IN ON OR ALL TIMES
HOT IN ON OR START
INSTRUMENT PANEL J/B (LEFT SIDE OF DASH)
J/B 4 (CENTER OF DASH)
JUNCTION
LCTY
LEFT "C" PILLAR)
LEFT FRONT DOOR COURTESY SWITCH (LEFT "B" PILLAR)
LEFT REAR DOOR COURTESY SWITCH (LEFT "C" PILLAR)
LT BLU WIRE
LT GRN WIRE
MAIN BODY ECU
MAP LIGHT ASSEMBLY
ON OFF
PCTY
PNK WIRE
RCTY
RED/GRN WIRE
RIGHT FRONT DOOR COURTESY SWITCH (RIGHT "B" PILLAR)
RIGHT REAR DOOR COURTESY SWITCH (RIGHT "C" PILLAR)
ROOM LIGHT ASSEMBLY 1
ROOM LIGHT ASSEMBLY 2
UNLOCK WARNING SWITCH
WHT WIRE
WHT/BLK WIRE
Go to component -> Courtesy lamps circuit -> ALTB IG BECU
