Front wiper/washer circuit for Scion xB II (2007-2010)
Front wiper/washer circuit
BLK WIRE
BLU WIRE
FRONT WASHER MOTOR (BEHIND RIGHT FRONT HEADLIGHT ASSEMBLY)
FRONT WASHER SWITCH
FRONT WIPER MOTOR (LEFT REAR OF ENGINE COMPT)
FRONT WIPER SWITCH
GRN WIRE
HIGH MIST
HOT IN ON OR START
INSTRUMENT PANEL J/B (BEHIND LEFT SIDE OF DASH)
MIST
OFF LOW INT
OFF LOW OFF INT INT
RED WIRE
WASHER FUSE
WHT WIRE
WHT/BLK WIRE
WINDSHIELD WIPER SWITCH
WIPER FUSE
WIPER RELAY SOLID STATE
