Cruise control circuit for Scion xB II (2007-2010)

28 20 44 35 IGSW BATT MREL 40 59 55 57 60 56 58 CCS EPA VPA VCPA 49 41 27 15 CANL CANH TC TACH ACCELERATOR POSITION SENSOR (LEFT SIDE OF DASH) BLK WIRE BLU RED/ WIRE BLU WIRE BLU/BLK WIRE BLU/WHT WIRE BRN WIRE COMPUTER DATA LINES SYSTEM CRUISE CONTROL SWITCH EFI 1 FUSE EFI MAIN FUSE EFI MAIN RELAY ENGINE CONTROL MODULE (LEFT SIDE OF ENGINE COMPT) ENGINE ROOM J/B (LEFT SIDE OF ENGINE COMPT) ENGINE ROOM R/B (ON LEFT SIDE OF ENGINE COMPT) ETA M+ M- PNK WIRE GRN WIRE GRY WIRE HOT AT ALL TIMES HOT AT ALL TIMES INSTRUMENT PANEL J/B (BEHIND LEFT SIDE OF DASH) STOP FUSE HOT IN ON OR START IGN FUSE JUNCTION CONNECTOR LT BLU WIRE LT GRN WIRE M/T MASS AIR FLOW METER (ON LEFT SIDE OF ENG COMPT) NCA WIRE ORG/ WIRE PNK A/T WIRE PNK WIRE PPL/BLU WIRE RED WIRE RED/BLU WIRE SPIRAL CABLE SPIRAL CABLE (IN STEERING COLUMN) STOP LIGHT SWITCH (ON BRACKET, ABOVE BRAKE PEDAL) THROTTLE POSITION SENSOR (ON THROTTLE BODY ASSEMBLY) VIO WIRE WHT WIRE WHT/BLK WIRE YEL WIRE

BLK WIRE BLU/BLK WIRE BRN WIRE CAN CONTROLLER CAN I/F CANL CANH FL- FL+ RL+ RL- FR- FR+ RR+ RR- CL CL+ COMBINATION METER COMPUTER DATA LINES SYSTEM CRUISE CONTROL CLUTCH SWITCH CRUISE IND DISPLAY ECU- IG 1 FUSE ECU-IG 2 FUSE GRN WIRE HOT IN ON OR START I/F I/F INSTRUMENT PANEL J/B (BEHIND LEFT SIDE OF DASH) J/B 4 (CENTER OF DASH) JUNCTION CONNECTOR LED DRIVER LEFT FRONT SPEED SENSOR (LEFT FRONT HUB ASSEMBLY) LEFT REAR SPEED SENSOR (LEFT REAR HUB ASSEMBLY) LT GRN WIRE METER FUSE PARK/NEUTRAL POSITION SWITCH (ON LEFT REAR OF TRANSMISSION) PNK WIRE RED WIRE RIGHT FRONT SPEED SENSOR (RIGHT FRONT HUB ASSEMBLY) RIGHT REAR SPEED SENSOR (RIGHT REAR HUB ASSEMBLY) SKID CONTROL ECU W/ ACTUATOR (LEFT SIDE OF ENGINE COMPT) VIO WIRE WHT WIRE WHT/BLK WIRE
