Manual a/c circuit for Scion xB II (2007-2010)

A/C AMPLIFIER (CENTER OF DASH) A/C COMPRESSOR A/C LED A/C PRESSURE SENSOR (RIGHT REAR OF ENGINE COMPT) A/C THERMISTOR (RIGHT SIDE OF DASH) BLK WIRE BLU WIRE BLU/WHT WIRE BRN WIRE CANH CANL SG-2 CRANKSHAFT POSITION SENSOR (ON LOWER FRONT OF ENGINE) ECU-IG 2 FUSE ENGINE CONTROL MODULE (LEFT SIDE OF ENGINE COMPT) ENGINE ROOM J/B (LEFT SIDE OF ENGINE COMPT) FAN CAN CAN FAN ETHW THW GRN WIRE GRY WIRE HOT AT ALL TIMES HOT IN ON OR START HTR FUSE HTR RELAY HTR-IG FUSE INSTRUMENT PANEL J/B (BEHIND LEFT SIDE OF DASH) J/B 4 (CENTER OF DASH) LT GRN WIRE NCA WIRE NE- NE+ ORG/ WIRE PNK WIRE PRE SOL+ IG+ SBLW TE SG-3 GND RED WIRE SOL- SOL+ VIO WIRE WHT WIRE WHT/BLK WIRE YEL WIRE

A/C SWITCH A/M, A/C SW AIR INLET CONTROL SWITCH (BEHIND CENTER OF DASH) BLK WIRE BLK/ WHT WIRE BLOWER MOTOR RESISTOR (BEHIND RIGHT SIDE OF DASH) BLU WIRE BLU/BLK WIRE CDS FAN FUSE DEF-LOGIC ECU- IG 1 FUSE ENGINE ROOM ENGINE ROOM R/B (ON LEFT SIDE OF ENGINE COMPT) F/R SWITCH FAN 1 RELAY FAN 2 RELAY FAN 3 RELAY FRS DAMPER SERVO MOTOR (BEHIND RIGHT SIDE OF DASH) GRN WIRE GRY WIRE HOT AT ALL TIMES HOT IN ON OR START INSTRUMENT PANEL J/B (BEHIND LEFT SIDE OF DASH) INTEGRATION CONTROL, PANEL ASSEMBLY J/B (LEFT SIDE OF ENGINE COMPT) ORG/ WIRE PNK REC WIRE PNK WIRE RDI FAN FUSE RED WIRE VIO WIRE WHT WIRE WHT/BLK WIRE YEL WIRE
