Scion xB II (2007-2010) left rear power window switch down Wiring diagram
This page shows the only wiring diagram for the component.left rear power window switch down, which is found in the car Scion xB II (2007-2010). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram left rear power window switch down (1 of 1)
BECU PWS
BLK WIRE
BLU WIRE
BRN WIRE
DOOR LOCKS SYSTEM
DOWN
ECU-B FUSE (ON LEFT SIDE OF ENGINE COMPT)
ENGINE ROOM R/B
GRN WIRE
HOT AT ALL TIMES
HOT AT ALL TIMES ENGINE ROOM J/B (LEFT SIDE OF ENGINE COMPT) ALT FUSE
INSTRUMENT PANEL J/B (BEHIND
LEFT FRONT POWER WINDOW MOTOR (IN LEFT FRONT DOOR)
LEFT REAR POWER WINDOW MOTOR (IN LEFT REAR DOOR)
LEFT REAR POWER WINDOW SWITCH DOWN
MAIN BODY ECU (LEFT SIDE OF DASH)
PNK WIRE
POWER FUSE
POWER WINDOW REGULATOR MASTER SWITCH
PWR RELAY
R/L DOOR FUSE
R/R DOOR FUSE
RED WIRE
RIGHT FRONT POWER WINDOW MOTOR (IN RIGHT FRONT DOOR)
RIGHT FRONT POWER WINDOW SWITCH DOWN
RIGHT REAR POWER WINDOW MOTOR (IN RIGHT REAR DOOR)
RIGHT REAR POWER WINDOW SWITCH
WHT WIRE
WHT/BLK WIRE
YEL WIRE
Go to component -> Power windows circuit -> LEFT REAR POWER WINDOW SWITCH DOWN
