Scion xB II (2007-2010) center air bag assembly sensor Wiring diagram
This page shows the only wiring diagram for the component.center air bag assembly sensor, which is found in the car Scion xB II (2007-2010). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram center air bag assembly sensor (1 of 1)
+SR -SR
-SL +SL
-SR -SL +SR +SL
1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 PD- PD+
BBL+
BBL- BCL- BCL+
BBR- BBR+ BCR- BCR+
BCL- BCL+
BCR+
BLK WIRE
BRN WIRE
BUCKLE SWITCH
CAN I/F
CANL PAON
CENTER AIR BAG ASSEMBLY SENSOR
COMBINATION METER
COMPUTER DATA LINES SYSTEM
CPU CAN CONTROLLER
GRN WIRE
ICD- ICD+ BBD+ SFD+ SFD- DBE+ DBE- DSP- DSP+ BBD-
LBE- LSP- LSP+
LED DRIVER
LEFT CURTAIN SHIELD AIR BAG SQUIB CIRCUIT
LEFT FRONT AIR BAG SENSOR
LEFT FRONT PRETENSIONER
LEFT FRONT SEAT INNER BELT SWITCH
LEFT FRONT SIDE AIR BAG SENSOR
LEFT REAR SIDE AIR BAG SENSOR
LEFT SIDE AIR BAG SQUIB
P- P+ D+ D-
PNK 1 2 3 4 5 6 7 8 9 10 WIRE
PNK WIRE
PR+ PR- SFR- SFR+ BBR+ ICR+ ICR- BBR- FSR+ FSR-
RED WIRE
RIGHT CURTAIN SHIELD AIR BAG SQUIB
RIGHT FRONT AIR BAG SENSOR
RIGHT FRONT SIDE AIR BAG SENSOR
RIGHT REAR SIDE AIR BAG SENSOR
RIGHT SIDE RIGHT FRONT PRETENSIONER AIR BAG SQUIB
SEAT POSITION AIR BAG SENSOR
SIL P-AB
SRS IND
WHT WIRE
WHT/BLK WIRE
YEL WIRE
YEL/BLK WIRE
YEL/GRN WIRE
YEL/RED WIRE
Go to component -> Supplemental restraints circuit (1 of 2) -> CENTER AIR BAG ASSEMBLY SENSOR
