Scion xB II (2007-2010) 4 5 21 6 1 23 altb ig Wiring diagram
This page shows the only wiring diagram for the component.4 5 21 6 1 23 altb ig, which is found in the car Scion xB II (2007-2010). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram 4 5 21 6 1 23 altb ig (1 of 1)
1 22 23 7 21 TR+ CANL CANH BDSU LSWD COMPUTER DATA LINES SYSTEM
4 5 21 6 1 23 ALTB IG
BACK DOOR LOCK ASSEMBLY (IN REAR TAILGATE)
BACK DOOR OPENER SWITCH
COURTESY
DOOR FUSE
ECU- IG 1 FUSE
ECU-B FUSE
ENGINE ROOM R/B (ON LEFT SIDE OF ENGINE COMPT)
FUSE (BEHIND LEFT SIDE OF DASH)
HOT AT ALL TIMES
HOT IN ON OR ACC
HOT IN ON OR START
INSTRUMENT PANEL J/B
J/B 4 (CENTER OF DASH)
LT GRN WIRE
MAIN BODY ECU (LEFT SIDE OF DASH)
ORG/ WIRE
RED WIRE
WHT WIRE
WHT/BLK WIRE
YEL WIRE
Go to component -> Back door opener circuit -> 4 5 21 6 1 23 ALTB IG
