Trunk, tailgate, fuel door circuit for Scion xB I (2003-2007)
Trunk, tailgate, fuel door circuit
BACK DOOR COURTESY SWITCH, BACK DOOR LOCK MOTOR (LEFT SIDE OF BACK DOOR)
BACK DOOR OPENER SWITCH
BACT
BLU WIRE
BLU/WHT WIRE
BLU/YEL WIRE
BRN/YEL WIRE
D/L FUSE
DOOR LOCK CONTROL RELAY
HOT AT ALL TIMES
INSTRUMENT PANEL J/B (BEHIND LEFT SIDE OF DASH)
INTERIOR LIGHTS,, DOOR LOCKS SYSTEMS
PCTY
RED WIRE
RED/WHT WIRE
WHT WIRE
WHT/BLK WIRE
YEL WIRE
