Scion xB I (2003-2007) wfse csw brl r+ Wiring diagram

ABS CUT RELAY ABS MTR RELAY ABS R/B (RIGHT REAR OF ENGINE COMPARTMENT) BK (RIGHT QUARTERPANEL) BLK WIRE BLK/BLU WIRE BLK/RED WIRE BLK/WHT WIRE BLU WIRE BLU/BLK WIRE BM FR+ FL- RR+ RL- BRN WIRE BRN/WHT WIRE BRN/YEL WIRE COLUMN) COMPUTER DATA LINES SYSTEM D/G MRF MR EB (LEFT REAR OF ENGINE COMPT) ECU-B FUSE ECU-IG FUSE FR- FL+ RR- RL+ FUSIBLE ABS FUSE LINK BLOCK (ON LEFT SIDE OF ENGINE COMPT) GRN WIRE GRN/RED WIRE GRN/WHT WIRE GRN/YEL WIRE GRY WIRE GRY/RED WIRE HOT AT ALL TIMES HOT IN ON OR START IG RIGHT KICK PANEL) IND WT VSCW INSTRUMENT PANEL J/B (BEHIND LEFT LT GRN/BLK WIRE LT GRN/RED WIRE PARKING BRAKE SWITCH (ON BASE OF PARK BRAKE LEVER) PKB WA BZ +BS PNK 20 21 WIRE PNK WIRE RED WIRE RED/BLU WIRE RED/WHT WIRE RED/YEL WIRE SIDE OF DASH) SKID CONTROL ECU (W/ ACTUATOR) (LEFT SIDE OF ENGINE COMPARTMENT) STEERING SENSOR (ON STEERING STOP FUSE STOPLIGHT SWITCH (ON BRACKET, ABOVE BRAKE PEDAL) TRAC OFF SWITCH TRC+ ENG+ NEO CANH TRC- ENG- TS CANL VIO WIRE VSC BUZZER (UPPER LEFT SIDE OF DASH) WFSE CSW BRL R+ WHT WIRE WHT/BLK WIRE WHT/BLU WIRE WHT/RED WIRE YAW RATE SENSOR (UNDER CENTER CONSOLE, REAR OF SHIFT LEVER) YEL WIRE
