Scion xB I (2003-2007) skid control ecu with actuator Wiring diagrams
This page contains all the electrical diagrams for the component. skid control ecu with actuator, in which he is found in the car Scion xB I (2003-2007). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..
Wiring diagram skid control ecu with actuator (1 of 2)
A/C CONDENSER FAN RESISTOR
BACK DOOR COURTESY SWITCH, BACK DOOR LOCK MOTOR
BACK DOOR OPENER SWITCH
BH (LEFT REAR DOOR)
BI (RIGHT REAR DOOR)
BJ (LEFT QUARTERPANEL)
BK (RIGHT QUARTERPANEL)
BL (CENTER OF BACK DOOR)
BLK WIRE
BLK/WHT WIRE
BM (LEFT SIDE OF BACK DOOR)
BRAKE FLUID LEVEL WARNING SWITCH
BRN WIRE
COMBINATION METER
EA (RIGHT REAR OR ENGINE COMPARTMENT)
EB (LEFT REAR OF ENGINE COMPARTMENT)
EFI RELAY ST RELAY
FAN 2 RELAY
FRONT WIPER MOTOR
FUEL PUMP
FUEL SENDER
HIGH MOUNTED STOP LIGHT
IF (LEFT DASH BRACE)
LEFT FRONT FOG LIGHT
LEFT FRONT PARKING LIGHT, TURN SIGNAL LIGHT
LEFT REAR COMBINATION LIGHT
LEFT REAR SIDE MARKER LIGHT
LICENSE PLATE LIGHT
PRESSURE SWITCH
RADIO, PLAYER
REAR WINDOW DEFOGGER
RIGHT FRONT FOG LIGHT
RIGHT FRONT TURN SIGNAL LIGHT, PARKING LIGHT LEFT SIDE TURN SIGNAL LIGHT
RIGHT REAR COMBINATION LIGHT
RIGHT REAR SIDE MARKER LIGHT
RIGHT SIDE TURN SIGNAL LIGHT
SKID CONTROL ECU WITH ACTUATOR
WHT/BLK WIRE
YAW RATE SENSOR
Go to component -> Ground distribution circuit (2 of 2) -> SKID CONTROL ECU WITH ACTUATOR
Wiring diagram skid control ecu with actuator (2 of 2)
A/C FUSE
ABS 2 FUSE
ABS CUT RELAY
ABS FUSE
ALT FUSE
BATTERY
BLK WIRE
BLK/RED WIRE
BLOWER MOTOR
BLU WIRE
COMBINATION METER, INTERIOR LIGHT, DOOR CONTROL RECEIVER, RADIO, PLAYER
COMBINATION SWITCH
D/L FUSE
DATA LINK CONNECTOR 3
DEF FUSE
DOME FUSE
DOOR LOCK CONTROL RELAY
ECU-B FUSE
EFI FUSE
EFI RELAY, ENGINE CONTROL MODULE
ENGINE ROOM R/B (ON LEFT SIDE OF ENGINE COMPT)
FAN 1 RELAY
FLASHER RELAY
FUSE
FUSIBLE LINK BLOCK (ON LEFT SIDE OF ENGINE COMPT)
GENERATOR
GRN WIRE
HAZ FUSE
HEATER RELAY
HORN FUSE
HORN RELAY
HTR
HTR FUSE
INSTRUMENT PANEL J/B (BEHIND LEFT SIDE OF DASH)
INTEGRATION CONTROL, PANEL
LEFT HEADLIGHT
LH H-LP FUSE
MAIN FUSE
MAX HOT, FOOT MODE SWITCH, DEFROSTER MODE DETECTION SWITCH
NCA WIRE
OBD FUSE
POWER FUSE
POWER RELAY
RDI FUSE
REAR WINDOW DEFOGGER RELAY, NOISE FILTER (REAR WINDOW DEFOGGER 1)
RED WIRE
RELAY
RH H-LP FUSE
RIGHT HEADLIGHT, HEADLIGHT RELAY
SKID CONTROL ECU WITH ACTUATOR
ST FUSE
ST RELAY
STARTER
STEERING SENSOR
STOP FUSE
STOP LIGHT SWITCH
TAIL FUSE
TO IGNITION SWITCH (DIAGRAM 2 OF 2)
WHT WIRE
YEL WIRE
Go to component -> Power distribution circuit (1 of 2) -> SKID CONTROL ECU WITH ACTUATOR
