Scion xB I (2003-2007) right front power window control switch Wiring diagram
This page shows the only wiring diagram for the component.right front power window control switch, which is found in the car Scion xB I (2003-2007). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram right front power window control switch (1 of 1)
BLK WIRE
BLU WIRE
DOWN
GAUGE FUSE
GRN WIRE
GRN/BLK WIRE
GRN/WHT WIRE
GRN/YEL WIRE
HOT AT ALL TIMES
HOT IN ON OR START
IE (LEFT KICK PANEL)
INSTRUMENT PANEL J/B (BEHIND LEFT SIDE OF DASH)
JUNCTION CONNECTOR 10 (LEFT FRONT DOOR)
LEFT FRONT
LEFT REAR
LEFT REAR POWER WINDOW CONTROL SWITCH
LOCK
NORMAL
POWER FUSE
POWER WINDOW MASTER SWITCH
POWER WINDOW MOTOR (LEFT FRONT) (IN LEFT FRONT DOOR)
POWER WINDOW MOTOR (LEFT REAR) (IN LEFT REAR DOOR)
POWER WINDOW MOTOR (RIGHT FRONT) (IN RIGHT FRONT DOOR)
POWER WINDOW MOTOR (RIGHT REAR) (IN RIGHT REAR DOOR)
PWR RELAY
RED WIRE
RED/BLK WIRE
RED/BLU WIRE
RED/YEL WIRE
RIGHT FRONT
RIGHT FRONT POWER WINDOW CONTROL SWITCH
RIGHT REAR
RIGHT REAR POWER WINDOW CONTROL SWITCH
RLD
RLU
RRD
RRU
SOLID STATE
WHT WIRE
WHT/BLK WIRE
WINDOW LOCK SWITCH
YEL WIRE
Go to component -> Power windows circuit -> RIGHT FRONT POWER WINDOW CONTROL SWITCH
