Scion xB I (2003-2007) low/ mist int int low/ mist Wiring diagram
This page shows the only wiring diagram for the component.low/ mist int int low/ mist, which is found in the car Scion xB I (2003-2007). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram low/ mist int int low/ mist (1 of 1)
BLK WIRE
COMBINATION SWITCH
FRONT WIPER MOTOR (ON LEFT SIDE OF FIREWALL)
FRONT WIPER SWITCH
GRN WIRE
GRY WIRE
HIGH OFF
HOT IN ON OR START
IE (LEFT KICK PANEL)
INSTRUMENT PANEL J/B (BEHIND LEFT SIDE OF DASH)
LOW/ MIST INT
LOW/ MIST INT INT LOW/ MIST
OFF
RED WIRE
SOLID STATE
WASHER MOTOR (ON RIGHT FRONT OF ENGINE COMPT)
WASHER SWITCH
WHT WIRE
WHT/BLK WIRE
WIPER FUSE
