Scion xB I (2003-2007) frs rec rec/frs Wiring diagram
This page shows the only wiring diagram for the component.frs rec rec/frs, which is found in the car Scion xB I (2003-2007). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram frs rec rec/frs (1 of 1)
AIR INLET CONTROL SERVO MOTOR (UNDER UPPER RIGHT SIDE OF DASH)
BLK WIRE
BLK/BLU WIRE
BLK/YEL WIRE
BLU WIRE
BLU/BLK WIRE
BLU/ORG WIRE
BLU/RED WIRE
BLU/WHT WIRE
BLU/YEL WIRE
CONTROL CIRCUIT
ECU-IG FUSE
ENGINE ROOM R/B (ON LEFT SIDE OF ENGINE COMPT)
F/D
FOOT
FOOT MODE SWITCH
FRS REC
FRS REC REC/FRS
GENERATOR
GRN/BLK WIRE
HEATER SUB 1 RELAY
HOT AT ALL TIMES
HOT IN ON OR START
HTR SUB 1 FUSE
IG MAX HOT NE GND
INLET AIR POSITION DETECTION SWITCH
INSTRUMENT PANEL J/B (BEHIND LEFT SIDE OF DASH)
MAX HOT SWITCH
MAX HOT, FOOT MODE SWITCH
POSITION SWITCHES
PTC AMPLIFIER (UNDER CENTER OF DASH)
PTC HEATER (BEHIND LEFT SIDE OF DASH)
RED WIRE
SG ALT MODE IN
WATER TEMPERATURE SENSOR (UNDER CENTER OF DASH)
WHT WIRE
WHT/BLK WIRE
YEL WIRE
YEL/BLK WIRE
Go to component -> Manual a/c circuit (2 of 2) -> FRS REC REC/FRS
