Front wiper/washer circuit for Scion xA I (2003-2006)
Front wiper/washer circuit
BLK WIRE
BLU WIRE
BLU/WHT WIRE
COMBINATION SWITCH
FRONT WIPER MOTOR (ON LEFT SIDE OF FIREWALL)
FRONT WIPER SWITCH
GRN WIRE
HIGH OFF
HOT IN ON OR START
IE (LEFT KICK PANEL)
INSTRUMENT PANEL J/B (BEHIND LEFT SIDE OF DASH)
LOW/ MIST INT
LOW/ MIST INT INT LOW/ MIST
OFF
SOLID STATE
WASHER MOTOR (ON RIGHT FRONT OF ENGINE COMPT)
WASHER SWITCH
WHT WIRE
WHT/BLK WIRE
WIPER FUSE
YEL WIRE
