Supplemental restraints circuit, without side airbag for Scion xA I (2003-2006)

+SR P+ P- SIL D- D+ +SL 1 2 3 4 5 6 7 8 9 10 11 12 PL- PL+ LSP+ AIR BAG SENSOR ASSEMBLY (LOWER CENTER OF DASH) BLK (OR LT BLU) WIRE BLK WIRE BLK/ORG (OR LT BLU) WIRE BLK/ORG WIRE BLK/WHT (OR LT BLU) WIRE BLK/YEL (OR WHT) WIRE BLU WIRE BRN (OR LT BLU) WIRE BRN/WHT (OR LT BLU) WIRE GAUGE FUSE GRN WIRE GRN/YEL WIRE HOT AT ALL TIMES HOT IN ON OR START IGNITION SWITCH INSTRUMENT PANEL J/B (BEHIND LEFT SIDE OF DASH) LBE- LSP- LEFT BUCKLE SWITCH (IN LEFT FRONT SEAT BELT BUCKLE) LEFT PRETENSIONER (NEAR BOTTOM OF LEFT "B" PILLAR) LOCK LT BLU WIRE PNK/BLK (OR WHT) WIRE PR- PR+ RBE+ RED WIRE RED/BLK WIRE RIGHT BUCKLE SWITCH (IN RIGHT FRONT SEAT BELT BUCKLE) SEAT POSITION AIRBAG SENSOR SL- TC -SR WHT (OR LT BLU) WIRE WHT WIRE WHT/BLK (OR LT BLU) WIRE WHT/RED (OR LT BLU) WIRE YEL (OR LT BLU) WIRE YEL WIRE YEL/BLK (OR LT BLU) WIRE YEL/BLK WIRE YEL/GRN (OR LT BLU) WIRE YEL/GRY (OR LT BLU) WIRE YEL/ORG (OR LT BLU) WIRE YEL/PNK (OR LT BLU) WIRE YEL/RED (OR LT BLU) WIRE YEL/VIO (OR LT BLU) WIRE

1 2 3 4 D+ D- 2004-05 AIR BAG SQUIB (FRONT PASSENGER AIR BAG ASSEMBLY) (RIGHT SIDE OF DASH) AIR BAG SQUIB (STEERING WHEEL PAD) BLK (OR LT BLU) WIRE BLK WIRE BLK/WHT (OR LT BLU) WIRE BLK/WHT WIRE BLK/YEL (OR WHT) WIRE BLK/YEL WIRE BLU WIRE BRN (OR LT BLU) WIRE BRN WIRE BRN/WHT (OR LT BLU) WIRE BRN/WHT WIRE COMBINATION METER DATA LINK CONNECTOR 3 (PARTIAL) (LOWER LEFT END OF DASH) ENGINE CONTROL MODULE (ECM) (BEHIND LOWER RIGHT SIDE OF DASH) FPS GRN WIRE GRY WIRE IF (LEFT DASH BRACE) INSTRUMENT PANEL J/B (BEHIND LEFT SIDE OF DASH) LEFT FRONT AIR BAG SENSOR (LEFT FRONT OF ENGINE COMPARTMENT) P+ P- PNK (OR LT (OR LT WIRE PNK/BLK (OR WHT) WIRE PNK/BLK WIRE RED WIRE RED/BLK WIRE RIGHT FRONT AIR BAG SENSOR (RIGHT FRONT OF ENGINE COMPARTMENT) SOLID STATE SRS WHT (OR LT BLU) WIRE WHT WIRE WHT/RED (OR LT BLU) WIRE WHT/RED WIRE YEL (OR LT BLU) WIRE YEL WIRE YEL/BLK (OR LT BLU) WIRE YEL/GRN (OR LT BLU) WIRE YEL/GRY (OR LT BLU) WIRE YEL/ORG (OR LT BLU) WIRE YEL/PNK (OR LT BLU) WIRE YEL/RED (OR LT BLU) WIRE YEL/VIO (OR LT BLU) WIRE
