Scion xA I (2003-2006) Courtesy lamps circuit

BACK DOOR COURTESY SWITCH (LEFT SIDE OF BACK DOOR) BJ (LEFT CENTER OF BACK DOOR) BLU WIRE BLU/YEL WIRE BRN/YEL WIRE COMBINATION METER DIODE (PERSONAL LIGHT) (LOWER LEFT END OF DASH) DOME FUSE DOOR IND DOOR LUGGAGE COMPARTMENT LIGHT DOOR PERSONAL LIGHT ENGINE ROOM R/B (ON LEFT SIDE OF ENGINE COMPT) HOT AT ALL TIMES IE (LEFT KICK PANEL) IF (LEFT DASH BRACE) ILLUMINATION CENTER BOX CLUSTER ILLUMINATION RELAY INSTRUMENT PANEL J/B (BEHIND LEFT SIDE OF DASH) JUNCTION CONNECTOR 7 (RIGHT CENTER OF DASH) JUNCTION CONNECTOR 9 (LEFT REAR CORNER OF LUGGAGE COMPT) LEFT FRONT DOOR COURTESY SWITCH (ON LEFT "B" PILLAR) LEFT REAR DOOR COURTESY SWITCH (ON LEFT ``C" PILLAR) OFF POWER RED WIRE RED/BLU WIRE RED/WHT WIRE RED/YEL WIRE RIGHT FRONT DOOR COURTESY SWITCH (ON RIGHT "B" PILLAR) RIGHT REAR DOOR COURTESY SWITCH (ON RIGHT ``C" PILLAR) WHT WIRE WHT/BLK WIRE YEL WIRE
