Back-up lamps circuit for Scion xA I (2003-2006)
Back-up lamps circuit
A/T
BACK-UP LIGHT SWITCH (ON RIGHT SIDE OF TRANSMISSION)
GAUGE FUSE
HOT IN ON OR START
INSTRUMENT PANEL J/B (BEHIND LEFT SIDE OF DASH)
J/C 9 (LEFT REAR CORNER OF LUGGAGE COMPT)
LEFT BACK-UP LIGHT
LEFT REAR COMBINATION LIGHT
M/T
PARK/NEUTRAL POSITION SWITCH (ON LEFT REAR OF TRANSMISSION)
RED/BLK WIRE
RED/WHT WIRE
RIGHT BACK-UP LIGHT
RIGHT REAR COMBINATION LIGHT
WHT/BLK WIRE
