Scion xA I (2003-2006) off tail light control switch Wiring diagram
This page shows the only wiring diagram for the component.off tail light control switch, which is found in the car Scion xA I (2003-2006). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram off tail light control switch (1 of 1)
BEAM IND
BLK WIRE
BLU WIRE
COMBINATION METER
COMBINATION SWITCH DIMMER SWITCH
ENGINE ROOM R/B (ON LEFT SIDE OF ENGINE COMPT)
HEAD
HOT AT ALL TIMES
INSTRUMENT PANEL J/B (BEHIND LEFT SIDE OF DASH)
JUNCTION CONNECTOR 4, 5
LEFT H-LP FUSE
LEFT HEADLIGHT
OFF TAIL LIGHT CONTROL SWITCH
RED WIRE
RED/BLU WIRE
RED/YEL WIRE
RIGHT H-LP FUSE
RIGHT HEADLIGHT
WHT WIRE
WHT/BLK WIRE
YEL WIRE
Go to component -> Headlights circuit -> OFF TAIL LIGHT CONTROL SWITCH
