Scion xA I (2003-2006) left remote control mirror Wiring diagram
This page shows the only wiring diagram for the component.left remote control mirror, which is found in the car Scion xA I (2003-2006). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram left remote control mirror (1 of 1)
BLK WIRE
BRN WIRE
FUSE
GRN WIRE
GRY WIRE
HOT IN ACC OR ON
INSTRUMENT PANEL J/B (BEHIND LEFT SIDE OF DASH)
JUNCTION CONNECTOR 1 (LEFT KICK PANEL)
LEFT REMOTE CONTROL MIRROR
LEFT RIGHT
LEFT UP
LT GRN WIRE
OPERATION SWITCH
RED WIRE
REMOTE CONTROL MIRROR SWITCH
RIGHT DOWN
RIGHT LEFT
RIGHT REMOTE CONTROL MIRROR
SELECT SWITCH
WHT WIRE
YEL WIRE
Go to component -> Power mirrors circuit -> LEFT REMOTE CONTROL MIRROR
