Scion xA I (2003-2006) left front side turn signal light Wiring diagrams
This page contains all the electrical diagrams for the component. left front side turn signal light, in which he is found in the car Scion xA I (2003-2006). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..
Wiring diagram left front side turn signal light (1 of 2)
BH (BEHIND LEFT QUARTERPANEL)
BJ (LEFT CENTER OF BACK DOOR)
BLK WIRE
CENTER CLUSTER SWITCH HAZARD SWITCH
COMBINATION METER
COMBINATION SWITCH
EA (RIGHT REAR OF ENGINE COMPT)
ED (RIGHT REAR OF ENGINE COMPT)
ED (RIGHT REAR OF ENGINE COMPT) BJ (LEFT CENTER OF BACK DOOR)
ER EHW
FLASHER RELAY
GAUGE FUSE
GRN WIRE
GRN/BLK WIRE
GRN/YEL WIRE
HAZ FUSE
HIGH MOUNTED STOP LIGHT
HOT AT ALL TIMES
HOT IN ON OR START
IF (LEFT DASH BRACE)
IG LL
INSTRUMENT PANEL J/B (BEHIND LEFT SIDE OF DASH)
J/C 1 (LEFT KICK PANEL)
J/C 8 (RIGHT KICK PANEL) IG
LEFT FRONT
LEFT FRONT SIDE MARKER LIGHT
LEFT FRONT SIDE TURN SIGNAL LIGHT
LEFT FRONT TURN SIGNAL LIGHT
LEFT LICENSE PLATE LIGHT
LEFT REAR COMBINATION LIGHT
LEFT TURN IND
LIGHT CONTROL SWITCH
OFF HEAD TAIL
ORG/ WIRE
PARKING LIGHT
RIGHT FRONT PARKING LIGHT
RIGHT FRONT SIDE MARKER LIGHT
RIGHT FRONT SIDE TURN SIGNAL LIGHT
RIGHT FRONT TURN SIGNAL LIGHT
RIGHT LICENSE PLATE LIGHT
RIGHT REAR COMBINATION LIGHT
RIGHT TURN IND
STOP FUSE
STOP LIGHT SWITCH (ON BRACKET, ABOVE BRAKE PEDAL)
TAIL FUSE
TAIL STOP
TURN
TURN SIGNAL SWITCH
TURN STOP TAIL
WHT WIRE
WHT/BLK WIRE
YEL WIRE
Go to component -> Exterior lamps circuit -> LEFT FRONT SIDE TURN SIGNAL LIGHT
Wiring diagram left front side turn signal light (2 of 2)
A/C CONDENSER FAN RESISTOR
BACK DOOR COURTESY SWITCH
BH (BEHIND LEFT QUARTERPANEL)
BI (BEHIND RIGHT QUARTERPANEL)
BJ (LEFT CENTER OF BACK DOOR)
BLK WIRE
BRAKE FLUID LEVEL WARNING SWITCH EFI RELAY ST RELAY
BRN WIRE
COMBINATION METER
EA (RIGHT REAR OR ENGINE COMPARTMENT)
ED (RIGHT REAR OF ENGINE COMPARTMENT)
FAN 2 RELAY
FRONT WIPER MOTOR
FUEL PUMP
FUEL SENDER
HIGH MOUNTED STOP LIGHT
IF (LEFT DASH BRACE)
LEFT FRONT PARKING LIGHT
LEFT FRONT SIDE MARKER LIGHT
LEFT FRONT SIDE TURN SIGNAL LIGHT
LEFT FRONT TURN SIGNAL LIGHT
LEFT LICENSE PLATE LIGHT
LEFT REAR COMBINATION LIGHT
PRESSURE SWITCH
RADIO, PLAYER
REAR WINDOW DEFOGGER
RIGHT FRONT PARKING LIGHT
RIGHT FRONT SIDE MARKER LIGHT RIGHT FRONT TURN SIGNAL LIGHT
RIGHT FRONT SIDE TURN SIGNAL LIGHT
RIGHT LICENSE PLATE LIGHT
RIGHT REAR COMBINATION LIGHT
SKID CONTROL ACTUATOR WITH ECU
WHT/BLK WIRE
Go to component -> Ground distribution circuit (2 of 2) -> LEFT FRONT SIDE TURN SIGNAL LIGHT
