Scion xA I (2003-2006) left front door key lock/ unlock switch, unlock detection switch, lock motor Wiring diagram
This page shows the only wiring diagram for the component.left front door key lock/ unlock switch, unlock detection switch, lock motor, which is found in the car Scion xA I (2003-2006). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram left front door key lock/ unlock switch, unlock detection switch, lock motor (1 of 1)
AIR BAG SENSOR ASSEMBLY
AIR INLET CONTROL SERVO MOTOR
BLK WIRE
BLOWER RESISTOR INSIDE SWITCH
BRN WIRE
CAMSHAFT POSITION SENSOR SHIELD
CENTER CLUSTER SWITCH
CIGARETTE LIGHTER
COMBINATION SWITCH
CRANKSHAFT POSITION SENSOR SHIELD
DATA LINK CONNECTOR 3
DATA LINK CONNECTOR 3 SHIELD
DOOR LOCK CONTROL RELAY
EC (LEFT TOP OF ENGINE)
ENGINE CONTROL MODULE
HEATED OXYGEN SENSOR (BANK 1 SENSOR 1) SHIELD
HEATED OXYGEN SENSOR (BANK 1 SENSOR 2) SHIELD
HEATER RELAY
IDLE AIR CONTROL VALVE
IE (LEFT KICK PANEL)
IG RIGHT KICK PANEL)
IGNITION COIL, IGNITER 1
IGNITION COIL, IGNITER 2
IGNITION COIL, IGNITER 3
IGNITION COIL, IGNITER 4
ILLUMINATION RELAY
INSTRUMENT PANEL J/B (BEHIND LEFT SIDE OF DASH)
J/C 1
J/C 8
KNOCK SENSOR SHIELD
LEFT FRONT DOOR KEY LOCK/ UNLOCK SWITCH, UNLOCK DETECTION SWITCH, LOCK MOTOR
NCA WIRE
O/D MAIN SWITCH
POWER RELAY FLASHER RELAY
POWER WINDOW MASTER SWITCH, LEFT DOOR LOCK CONTROL SWITCH
PTC AMPLIFIER
REAR WINDOW DEFOGGER RELAY
REMOTE CONTROL MIRROR SWITCH
RHEOSTAT
RIGHT DOOR LOCK CONTROL SWITCH
RIGHT FRONT DOOR KEY LOCK, UNLOCK SWITCH, LOCK MOTOR
SHIFT LOCK CONTROL SWITCH
UNLOCK WARNING SWITCH
WHT WIRE
WHT/BLK (OR LT BLU) WIRE
WHT/BLK WIRE
Go to component -> Ground distribution circuit (1 of 2) -> LEFT FRONT DOOR KEY LOCK/ UNLOCK SWITCH, UNLOCK DETECTION SWITCH, LOCK MOTOR
